当机械中有振动或冲击力浸染时，滑轨与滑块很可能会偏离原来的固定地位，而影响运行精度

操作寿命。因此直线导轨与滑轨滑块之间的固定就很重要。

1、推拔固定法

藉由对推拔的锁紧来施压，过大的锁紧力易造成滑轨弯曲或外侧肩部变形，所以安装时要特别注意锁紧力的适当性。

2、压板固定法

直线导轨与滑块侧面需略微突出床台与工作台边缘，而压板需加工逃槽，以防止安装时与滑轨或滑块的角部产生干预。

3、滚柱固定法

滚柱是利用螺栓头部斜度的推进来施压，所以要特别注意螺栓头部的位置。

4、定位螺栓固定法

提醒直线导轨因为安装空间的限制，使用的螺栓尺寸不可太大。

免责声明丨 部分内容来源网络！本文仅供交流学习 , 版权归属原作者，部分图片、内容推送时未能及时与原作者取得联系，若来源标注错误或侵犯到您的权益烦请告知，我们将立即删除.

QQ邮箱：2870202745@qq.com

网易邮箱：LS13645201509@163.com

When there is vibration or impact force in the machinery, the sliding rail and slider are likely to deviate from their original fixed position, which affects the operating accuracy

Operating lifespan. Therefore, the fixation between the linear guide rail and the sliding rail slider is very important.

1. Push-pull fixation method

By applying pressure to the locking force of push and pull, excessive locking force can easily cause the slide rail to bend or the outer shoulder to deform. Therefore, special attention should be paid to the appropriateness of the locking force during installation.

2. Pressure plate fixation method

The side of the linear guide rail and slider should slightly protrude from the edges of the bed and worktable, while the pressure plate needs to be machined with escape grooves to prevent interference with the corners of the slide rail or slider during installation.

3. Roller fixing method

Rollers use the inclination of the bolt head to apply pressure, so special attention should be paid to the position of the bolt head.

4. Positioning bolt fixation method

Reminder: Due to installation space limitations, the bolt size used for linear guides should not be too large.
