产品描述
料位仪的接线方法: 1. 阻旋式:要看清电压等级。内部有六个端子,两根电源线,一根接地线,三根信号线(公共线、L线、H线)。2.电容式料位仪:有四个端子需要接线,两根电源线,两根信号线,其中一根电源线可以和信号线的L线或H线共接一根线的。(上料位接公共线和H线;下料位接公共线和L线)3. 电容式:要看清电压等级,我厂发送罐一般都用24V的。内部共有4个端子,接线图见盖子内侧的说明。端子1为24V电源正,端子2为24V电源负,端子3端子4是一组无源常开点。根据图纸,其中一根电源线可以和端子3或端子4共接一根线。如果无法识别同一个罐上的上下料位,只要观察上面标签贴的型号,一般S1000的罐子,上料位为350MM,下料位为1600MM。4. 液料桶的料位计中浮球式、折角式只要接两根线就可以了,杆式的要接三根线(上料位线、下料位线、公共线)
